Singer Model 319 Parts - Piano Key Zigzag Machine

Singer Model 319 - Piano Key Stitch Control with Expandable Patterns

Find vintage genuine and quality aftermarket replacement parts for the Singer Model 319, introduced around 1956 and manufactured until 1961 in Kilbowie, Scotland. This distinctive full-size machine features piano-style keys for stitch control and expandable pattern capabilities with Type A cams.

History of the Singer Model 319

Introduced around 1956 as an evolution of the Singer 306, the 319 added improved stitch control through its distinctive piano-style keys and expanded decorative capabilities. Production continued until 1961, primarily at Singer's Kilbowie, Scotland factory (designated as 319K).

• Production Period: 1956-1961
• Manufacturing Site: Primarily Kilbowie, Scotland (319K)
• Evolved from: Singer Model 306
• Distinctive Feature: Piano-style keys on top of machine for stitch selection

Why the Model 319 is Special

• Piano Key Control - Unique piano-style keys on top of machine for intuitive stitch selection
• Built-In Stitches - Zigzag and decorative stitches without requiring cams
• Expandable Patterns - Type A pattern cams add up to 25 additional decorative stitch patterns
• Full-Size Machine - 14-5/8" base provides ample workspace
• Distinctive Styling - Typically finished in attractive pale green
• Mechanical Complexity - Favorite among vintage sewing enthusiasts for its engineering

Critical: Special Needle Requirement

⚠️ IMPORTANT: The Singer 319 requires special 206x13 needles with shorter points. Using standard 15x1 needles can damage the bobbin case. Always use 206x13 needles specifically designed for this model. This is one of the most important things to know about maintaining your 319.

Unique Bobbin System

• Industrial-Style Bobbins - Uses 55623 type bobbins (different from both Class 66 and 15)
• Vertical Mount - Bobbin case mounts vertically, accessed by tilting machine backward
• Tilt-Back Design - Base includes mechanism to hold machine in tilted position for easier bobbin access
• Professional Capacity - Industrial-style bobbins provide ample thread capacity

Drive System

• External Motor - Powered by Singer BA series external motor with V-belt
• Timing Belt - Stapled fabric type, similar to Models 206 and 306
• Reliable Power - External motor design allows for easy maintenance and replacement

Piano Key Stitch Control

The 319's distinctive piano-style keys on top of the machine provide intuitive stitch selection. Built-in zigzag and decorative stitches are accessed through these keys, and the system can be expanded with Type A pattern cams for up to 25 additional decorative stitch patterns.

Singer 319 vs. Singer 306

Available Replacement Parts & Accessories

• 206x13 Needles - Special needles with shorter points required for this model (CRITICAL - do not use 15x1 needles!)
• Bobbins - Type 55623 bobbin
• Bobbin Cases - Vertical-mount bobbin cases for the tilt-back system
• Type A Pattern Cams - Decorative stitch cams for expanded pattern capabilities (up to 25 patterns)
• Presser Feet - Low shank presser feet for straight, zigzag, and decorative stitching
• BA Series Motors - Replacement external motors and V-belts
• Timing Belts - Stapled fabric timing belts
• Electrical Components - Power cords, switches, and light bulbs
• Mechanical Parts - Tension assemblies, feed dogs, and internal components
• Restoration Parts - Faceplates, decals, and cosmetic components for pale green finish

Maintenance & Care

The Model 319's tilt-back bobbin access system requires familiarity with the tilting mechanism. Always ensure the machine is properly positioned when tilted for bobbin changes. The vertical bobbin case must be properly seated for correct tension. The piano key mechanism should be kept clean and free of lint for smooth operation. Pattern cams should be properly seated for correct stitch formation.

The external motor and V-belt system require occasional belt replacement and motor maintenance. The stapled fabric timing belt should be inspected regularly for wear.

Most importantly: always use 206x13 needles - using standard 15x1 needles can damage the bobbin case.

Collector Appeal

The Model 319 is a favorite among vintage sewing enthusiasts for its mechanical complexity, distinctive piano key control, and stitch variety. The pale green finish is attractive and distinctive. The ability to expand stitch patterns with Type A cams makes it versatile for creative sewing projects. The full-size workspace and industrial-style bobbins make it practical for serious sewing work.

Need help finding the right part for your Model 319? Our team has over 20 years of experience with vintage Singer machines. Whether you need special 206x13 needles, bobbins, Type A pattern cams, or help with threading and setup, we can help you find exactly what you need. Remember: this machine requires special 206x13 needles and bobbins - we'll make sure you get the correct parts for this distinctive piano key machine.
